Specifications
| Size type | Ø×L （mm) | Filtration area (m²) | Flow(m³/h) |
| #1 | 180×430 | 0.25 | ~20 |
| #2 | 180×810 | 0.5 | ~40 |
| #3 | 105×230 | 0.09 | ~6 |
| #4 | 105×380 | 0.16 | ~12 |
| #5 | 150×560 | 0.25 | ~20 |
Accuracy range: 0.3–200µm, generally available 1, 5, 10, 25, 50, 75, 100, 150, 200µm, etc.
Retention efficiency: The surface fixture mesh structure is conducive to high-efficiency surface filtration, and microporous nylon can retain ≥99% of particles
Advantages and Features
High dust capacity & low pressure loss: Gradient filter structure extends life and reduces replacement frequency.
High temperature adaptability: room temperature <150°C, medium temperature ≤190°C for various liquids.
Strong durability: Stable sewing, high toughness of material, strong tensile force, and difficult to break.
Cleanable and reusable: smooth surface, easy to wash or chemical/backwash cleaning.
Application scenarios
Industrial liquid filtration: ink, coating, metal processing liquid, cutting fluid, etc.
Food/Beverage/Pharmaceuticals: Drinking water, beverages, syrup filtration (compliant with food grade requirements).
Chemical and Electronics: Organic solvents, chemical reagents, ultrapure water pretreatment.
Others: Cooling water treatment, lubricating oil filtration and other medium temperature-free acid environments.
