Specifications
| Size type | Ø×L （mm) | Flow(m³/h) | Filtration area (m²) | Material layer/mesh range |
| #1 | 180×410–430 | ~20 m³/h (20 t/h) | ~0.24 m² | 20–500 mesh （25–1000 µm） |
| #2 | 180×810–830 | ~40 m³/h (40 t/h) | ~0.48 m² | |
| #3 | 102–105×210–230 | ~6 m³/h | ~0.08 m² | |
| #4 | 102–105×356–380 | ~12 m³/h | ~0.16 m² | |
| #5 | 150×550–560 | ~18–20 m³/h | ~0.24 m² | |
| Customized | Ø4-200 mm× up to 1016 mm or more |
Filtration level: Typical 25–800µm (1–500 mesh)
Efficiency: up to 99% or more
Advantages and Features
Strong, high temperature, high chemical tolerance: suitable for harsh environments.
Durable, repeatable cleaning: reusable to reduce costs.
High throughput, low resistance: The mesh has high permeability and is suitable for high flow or high pressure conditions.
Diverse sizes, enhanced customization: Support non-standard sizes, special shapes, explosion-proof applications.
Application scenarios
Chemical solvents, acid and alkali filtration.
Food/beverage/beer/dairy products, etc. require a clean environment.
Pharmaceutical and high-end chemical liquid purification.
Liquid-solid separation of oil and gas, lubricating oil, metal processing liquid, etc.
Flue gas, compressed air, gas filtration.
