Stainless Steel Mesh Filter Bag Features

A stainless steel mesh filter bag is a precision filter element woven from metal wire. It is made of stainless steel materials such as 304, 316 and 316L, and made by multi-layer weaving or sintering process. It is used for solid/liquid/gas separation in high temperature and corrosive environments.

Stainless steel filter bag Core Features:

-Extreme Environmental Adaptability

→ Resistant to high temperatures (550°C), high pressure and strong corrosive media, replacing aging-prone chemical fibre filter bags.

-Long Lifespan & Regenerability:

→ High mechanical strength and fatigue resistance, capable of over 50 ultrasonic cleaning/reverse blowing cycles.

-Pollution-Free & Sterilizable:

→ No fiber shedding, compliant with FDA standards; supports steam sterilization (pharmaceutical/food-grade applications).

-High-Precision Stability:

→ Rigid metal mesh structure maintains consistent filtration accuracy, regardless of pressure fluctuations.

-Low Operating Costs:

→ Reduced replacement frequency during downtime, high medium recovery rate (e.g., precious metal catalysts).

Stainless Steel Bag Filter Key Product:

Features: Material: 304 (general), 316 (chlorine-resistant), 316L (ultra-low carbon, grain boundary corrosion-resistant).

Weaving Structure: Plain weave (standard precision), Twill weave (high strength), Saddle weave (ultra-precision).

Connection Methods: Stainless steel quick-connect ring, Flange welding, Threaded connection (compatible with various filters).

Support Framework: Optional built-in perforated basket or diamond mesh (prevents bag collapse, enhances pressure resistance).

Surface Treatment: Electrolytic polishing (reduces adhesion), PTFE coating (resistant to oil particles).

Certification: ISO 9001, ASME BPE (pharmaceutical), EHEDG (food hygiene)
