Specifications
| specifications | Typical values or ranges |
| Ore diameter | 0.2–300µm (Common: 0.5–100µm) |
| Porosity | 35–60% |
| Thickness (wire mesh) | 1.7–3mm |
| Temperature tolerance | -200℃ to +600–800℃ |
| Maximum differential pressure | Wire mesh type is about 30MPa, powder type ≥5MPa |
| Interface form | DOE, 222/226, threads, flanges, etc. |
| size | OD 30–200mm, length 125–1000+mm |
1.Filtration performance
Pore size/filtration accuracy: range 0.2–300µm, common specifications are 0.5, 1, 3, 5, 10, 20, 25, 50, 100, 200µm, etc.
Filtration efficiency: Most models ≥95% (equivalent to bubble point or rated pressure drop test).
High porosity, low pressure loss, high throughput, suitable for high flow systems.
Temperature and pressure adaptability
Temperature resistance range: from -200℃ to +600–800℃ (depending on material and structure).
Pressure bearing capacity: The powder type can reach 5MPa (≈50bar) standard, and some high-pressure designs can reach 30MPa; the wire mesh type can bear 30MPa operating pressure.
High mechanical strength: stable structure, impact resistance, can be used repeatedly for flushing.
2.Dimensions and interface forms
OD: Commonly available: 30, 40, 50, 60, 64, 70, 80mm.
Length: 5″, 10″, 20″, 30″, 40″ standard, and 100–1000mm non-standard.
Interface/end type: Support DOE, dual O-ring 226/222, 1″ BSP threads, flanges and quick installation, etc.
3.Cleaning and regeneration characteristics
Supports high-pressure recoil, chemical cleaning (acid and alkali), ultrasonic treatment, and the performance can still be restored after multiple times ≥90%.
High durability and reusable, suitable for long-term applications and reduces life cycle costs.
Application scenarios
High temperature/high pressure fluid filtration: such as steam, hot oil, natural gas.
Chemical corrosive media: strong acids, strong alkalis, organic solvents, etc.
Pharmaceutical/Food/Electronics: No shedding, SIP/CIP-free, pollution-free.
Oil/natural gas/catalytic process: oil, water, gas-solid separation and filtration.
