Specifications
1.Filtration accuracy and pore characteristics
Filtration pore size range: Customizable 0.1–200µm (common 0.45, 1, 3, 5, 10, 20, 50, 80, 100, 200µm).
Porosity: 50–80%, and has uniform distribution and gradient pore size design to improve filtration efficiency and pollution capacity.
Typical bubble point value (sintered felt): 0.8–3.6kPa (860–3600Pa, depending on the aperture).
2.Temperature and pressure tolerance
Operating temperature range: up to 480–600°C (some models can even adapt to 900°C), and can operate safely in short-term high temperature environments.
Maximum pressure difference: about 0.4MPa (4bar) at room temperature; special design can withstand 5MPa, or even reach 60MPa.Extremely high mechanical strength: tensile strength ≥80MPa, significant impact and fatigue resistance.
3.Dimensions and interfaces
Diameter: Optional φ25, 30, 50, 60, 65, 70, 80mm, or customizable to 4–220mm.
Length: 5″, 10″, 20″, 30″, 40″ (127–1,016mm), and custom 100–1,000mm or above is also supported.
Interface form: DOE/single-ended/double-ended seal (222/226), thread (M20/M30), flat crimp joint, flange, etc.
4.Cleaning and regeneration capabilities
Can be physically cleaned (backwash water or gas, ultrasonic) and chemically cleaned (acid, alkali, oxidant, enzyme, surfactant), with excellent reusable performance and long life.
Stable structure and wear resistance, high backflushing efficiency, and performance recovery rate after use is higher than 90%.
Advantages and Features
1.High temperature resistance·High pressure resistance: The temperature can reach 480–600°C and the pressure can reach dozens of MPa.
2.Corrosion-resistant and impact-resistant: 316L material, suitable for extreme chemical environments.
3.Regeneration and use: chemical, physical cleaning, reuse, and reduce costs.
4.Stable structure: uniform pore size, no fiber shedding, high precision and stable.
5.Large dust and low pressure loss: high porosity and smooth process.
Application scenarios
1.High temperature gas filtration: steam, natural gas, industrial atmosphere filtration
2.Corrosive liquid/viscous fluid: acid and alkali solvent, melt, ink, reaction medium
3.Precision filtration: food and beverage, medicine, biological agents
4.Petrochemical and catalysis: intermediate recovery in petroleum and chemical processes and CAPTA metal filtration
