Views: 0 Author: Site Editor Publish Time: 2026-07-09 Origin: Site
High Flow Capacity
High Flow Capacity: Process larger volumes of water with fewer cartridges, reducing maintenance time and lowering operating costs.
Large Filtration Area
Large Filtration Area: The pleated design provides more filtration surface, extending service life and maintaining stable flow performance.
Reduce Frequent Cartridge Changes
Reduce Frequent Cartridge Changes: High dirt-holding capacity helps extend replacement intervals, minimizing downtime in continuous production.
Protect Critical Equipment
Protect Your RO Membranes: Efficient pre-filtration removes suspended particles before they reach expensive downstream equipment.
Large Effective Filtration Area
Up to 8 m² Filtration Area: A larger filtration surface supports higher contaminant retention and longer operating cycles.
Wide Micron Selection
0.2–100 Micron Options: Multiple filtration ratings allow precise filtration for environmental, food and pharmaceutical processes.
Food & Beverage Processing
Reliable Food Processing: Deliver consistent filtration performance for process water, ingredients and beverage production.
Pharmaceutical Water Systems
Designed for Pharmaceutical Water: Maintain stable filtration efficiency for purified water and critical process applications.
Fewer Cartridges Required
Replace Multiple Standard Cartridges: One high flow cartridge can reduce the number of filter elements required, simplifying system maintenance.
Lower Pressure Drop
Lower Pressure Drop: The optimized pleated structure helps maintain high flow while reducing energy consumption compared with conventional filter designs.
| Parameter | Common Specification for European Market |
|---|---|
| Filter Media | Polypropylene (PP), Glass Fiber (GF) |
| Support Layer | Polypropylene |
| Core | Polypropylene / Glass Fiber Reinforced PP |
| Cage | Polypropylene |
| End Cap | Polypropylene |
| Seal Material | EPDM / Silicone / Viton (FKM) / NBR |
| Filtration Rating | 0.2, 0.5, 1, 3, 5, 10, 20, 40, 70, 100 μm |
| Efficiency | Nominal / Absolute (Up to 99.98%) |
| Cartridge Length | 20", 40", 60" (80" optional) |
| Outside Diameter | 6" (152 mm) |
| Flow Direction | Inside → Outside |
| Maximum Flow Rate | 20–70 m³/h per cartridge (depending on length) |
| Filtration Area | Up to 8 m² |
| Maximum Operating Temperature | 80°C (PP) |
| Maximum Differential Pressure | 3.0–4.0 bar |
| Recommended Change-Out Pressure | 2.1–2.4 bar |
| Construction | 100% Thermal Welded (No Glue) |
| Compliance | FDA, EU 1935/2004, EU 10/2011 |
| Manufacturing Environment | Cleanroom Production |
| Typical Applications | RO Pre-filtration, Process Water, Beverage, Pharmaceutical Water, Chemicals, Wastewater |
| Item | Recommended |
|---|---|
| Length | 40"、60" |
| Micron | 1、5、10、20 μm |
| Material | 100% PP |
| Diameter | 6 inch (152 mm) |
| Seal | EPDM / Silicone |
| Flow | 35–70 m³/h |
| Temperature | ≤80°C |
| Application | Food & Beverage / Pharmaceutical / Water Treatment / Environmental Protection |
High Flow Pleated Filter Cartridge Export Packaging
| Item | Specification |
|---|---|
| Individual Packaging | Each cartridge is sealed in a PE protective bag. |
| Inner Packaging | Packed in a strong corrugated carton with protective inserts. |
| Outer Packaging | Export-grade 5-layer corrugated carton. |
| Pallet | Fumigation-free plywood pallet or plastic pallet (optional). |
| Protection | Shockproof, moisture-resistant and dustproof packaging. |
| Labeling | Product model, micron rating, batch number and carton label available. |
| OEM Packaging | Custom logo, labels and cartons available upon request. |
| Container Loading | Suitable for sea, air and land transportation. |
Individually sealed for cleanliness and contamination protection
Strong export cartons to reduce transportation damage
Moisture-resistant packaging for long-distance shipping
Palletized packing available for easier loading and unloading
OEM packaging and private labeling supported
Suitable for FCL and LCL international shipments
Filter Cartridge FAQ
FAQ 1. What filtration ratings are available?
Our High Flow Pleated Filter Cartridges are available in 0.2, 0.5, 1, 3, 5, 10, 20, 40, 70 and 100 micron ratings to meet different filtration requirements for environmental, food, beverage and pharmaceutical applications.
FAQ 2. Are your filter cartridges suitable for food and beverage applications?
Yes. The cartridges are manufactured from food-grade polypropylene materials and are suitable for food and beverage processing. Products can be supplied to meet applicable food-contact requirements when required by the project.
FAQ 3. Can one high flow cartridge replace multiple standard cartridges?
Yes. A single high flow cartridge can typically replace multiple conventional 10-inch filter cartridges, reducing the number of filter housings, lowering maintenance costs and shortening cartridge replacement time.
FAQ 4. What is the maximum operating temperature?
The recommended maximum continuous operating temperature is up to 80°C (176°F) for polypropylene construction, depending on the operating pressure and process conditions.
FAQ 5. How long does a high flow filter cartridge last?
Service life depends on the feed water quality, contaminant loading, operating pressure and filtration rating. High dirt-holding capacity generally provides a longer service life than standard filter cartridges.
FAQ 6. Which industries are these cartridges suitable for?
They are widely used in:
Environmental water treatment
Food and beverage processing
Pharmaceutical water systems
RO pre-filtration
Chemical processing
Industrial process water
Electronics manufacturing
Municipal water treatment
FAQ 7. What sealing materials are available?
We offer several O-ring materials to suit different fluids and operating conditions, including:
EPDM
Silicone
Viton (FKM)
NBR
FAQ 8. What are the advantages of inside-to-outside flow?
The inside-to-outside flow design helps retain contaminants inside the cartridge during replacement, reducing the risk of secondary contamination while providing a larger effective filtration area and lower pressure drop.
FAQ 9. Are OEM and customized specifications available?
Yes. We provide OEM and customized solutions, including:
Micron ratings
Cartridge lengths
End cap configurations
Seal materials
Labels and packaging
Private branding
FAQ 10. How do I choose the right high flow filter cartridge?
When selecting a cartridge, consider:
Required micron rating
Flow rate
Water quality
Operating temperature
Differential pressure
Chemical compatibility
Application (food, pharmaceutical, environmental or industrial)
Our technical team can recommend the most suitable filtration solution based on your operating conditions.
