Key Features
✔ Exceptional Efficiency – Removes 99.9% of droplets as fine as 1 micron
✔ Low Pressure Drop – Optimized mesh geometry reduces energy consumption
✔ Robust Material Options – SS304, SS316L, Monel, Inconel, and specialty alloys
✔ Customizable Design – Variable density and thickness for specific process needs
✔ Easy Installation – Flexible structure adapts to various vessel geometries
Applications
Oil & Gas – Separators, scrubbers, knockout drums
Chemical Processing – Distillation columns, evaporators, reactors
Power Generation – Steam drums, flue gas treatment
Air Pollution Control – Scrubbers, exhaust systems
HVAC & Refrigeration – Air washers, chillers
Advantages
✅ High Void Volume – Maximizes dirt holding capacity and reduces clogging
✅ Corrosion Resistance – Performs in acidic, alkaline, and saline environments
✅ Reusable & Cleanable – Suitable for CIP/SIP processes
✅ Cost-Effective – Lowers operational costs by minimizing product loss and emissions
Specifications
Materials: SS304, SS316L, Duplex, Monel, Inconel, Polypropylene (PP)
Standard Density: 120–280 kg/m³
Temperature Range:
Metal Meshes: –200°C to +540°C
Polymer Meshes: –40°C to +100°C
Efficiency: 99.9% for droplets ≥3 microns
Pressure Drop: <250 Pa at 1–3 m/s face velocity
