Specifications
1.Material structure
Use PA monofilament or needle felt, and the surface can be burned or coated to prevent the fiber from falling off. The edges are usually sewn or hot-welded, with soft or metal seals.
2.Filtration accuracy and efficiency
Pore size range: 0.3–200µm (commonly used: 1, 5, 10, 25, 50, 100µm).
Filtration efficiency: about 85% at nominal accuracy, and the surface filtration of microporous membrane can reach ≥99%.
3.Temperature and pressure characteristics
Temperature resistance: up to ~135–190°C, much higher than PP materials.
Pressure: Can be used to about 2.0bar (room temperature) and 1.0bar (high temperature).
4.Physical properties
The size can be customized with the same SS disk: OD 100–300mm, and the thickness is generally several millimeters.
High tensile strength, wear-resistant and tear-resistant.
5.Performance Advantages
Keep the structure stable at high temperature; the surface is smooth and easy to clean (washable/solvent); economical and lightweight; suitable for food-grade industry and chemical liquid filtration.
Application scenarios
1.Medium temperature liquid filtration: coatings, inks, chemical solvents, cutting fluids, etc.
2.Pre-filtering of pharmaceutical, food, and electronic solutions.
3.Clean air/gas filtration assembly.
