Efficient Particle Removal: Captures suspended solids and fine particles to help maintain stable liquid quality throughout the filtration process.
Consistent Flow Performance: The pleated design provides a large filtration area to support reliable flow while helping reduce pressure drop.
Reduce Frequent Cartridge Changes: High dirt-holding capacity helps extend service life, reducing maintenance interruptions in continuous operations.
Protect Downstream Equipment: Removes contaminants before they reach pumps, valves, and RO membranes, helping improve system reliability.
Wide Micron Selection: Available from 0.1 to 100 microns to support a broad range of industrial filtration requirements.
Multiple Size Options: Offered in 10", 20", 30", and 40" lengths for compatibility with many standard filtration systems.
Reliable for Food & Beverage Processing: Suitable for water filtration, ingredient processing, and beverage production where consistent filtration is required.
Built for Industrial Water Treatment: Supports stable operation in manufacturing plants, process water systems, and RO pretreatment applications.
Larger Filtration Area: The pleated structure provides more effective filtration surface than many non-pleated designs, helping extend replacement intervals.
Flexible System Compatibility: Multiple end cap configurations fit a wide range of filter housings, making installation and replacement more convenient.
Pleated Filter Cartridge Specifications
Target Market: Southeast Asia (Food & Beverage / Manufacturing / Water Treatment)
| Parameter | Specification |
|---|---|
| Product Name | Pleated Filter Cartridge |
| Filter Media | Polypropylene (PP), PES, PTFE, Nylon (PA), Glass Fiber (Optional) |
| Support Layer | Polypropylene (PP) |
| Core & Cage | Polypropylene (PP) |
| End Caps | Polypropylene (PP) |
| Seal Material | Silicone, EPDM, NBR, FKM (Viton) |
| Filtration Rating | 0.1, 0.22, 0.45, 1, 3, 5, 10, 20, 30, 50, 100 μm |
| Cartridge Length | 10", 20", 30", 40" |
| Outside Diameter | 68–70 mm |
| Inside Diameter | 28 mm |
| Structure | Pleated Depth Filtration |
| Connection Type | DOE, 222 Flat, 222 Fin, 226 Flat, 226 Fin |
| Maximum Operating Temperature | Up to 80°C (Depending on Filter Media) |
| Maximum Differential Pressure | 4.0 bar @ 25°C |
| Recommended Replacement Pressure | 2.4 bar |
| Flow Direction | Outside to Inside |
| Typical Flow Rate | Up to 30 m³/h (Model Dependent) |
| Removal Efficiency | Up to 99.98% (Selected Micron Ratings) |
| Compatibility | Water, Process Liquids, Food & Beverage Liquids, Chemicals (Media Dependent) |
| Manufacturing Standard | ISO 9001 Quality Management |
| Food Contact Option | Food-contact compliant materials available upon request |
| Sterilization Option | Hot Water and Chemical Sanitization Compatible (Selected Models) |
| Packaging | Individual PE Bag + Export Carton |
Typical Micron Ratings
| Micron Rating | Typical Application |
|---|---|
| 0.1 μm | Fine Process Filtration |
| 0.22 μm | Critical Liquid Filtration |
| 0.45 μm | Beverage Processing |
| 1 μm | RO Pretreatment |
| 5 μm | Water Treatment |
| 10 μm | Industrial Process Water |
| 20 μm | General Liquid Filtration |
| 50–100 μm | Coarse Particle Removal |
Common Materials by Application
| Industry | Recommended Filter Media |
|---|---|
| Food & Beverage | PP, PES |
| Bottled Water | PP |
| RO Pretreatment | PP |
| Industrial Water Treatment | PP |
| Electronics Manufacturing | PES |
| Chemical Processing | PTFE |
| General Manufacturing | PP |
Available Sizes
| Length | Typical Use |
|---|---|
| 10 Inch | Small Filtration Systems |
| 20 Inch | Medium Flow Applications |
| 30 Inch | Industrial Process Filtration |
| 40 Inch | High-Capacity Water Treatment |
Pleated Filter Cartridge Application
| Application | Typical Industries |
|---|---|
| Pharmaceutical Water Filtration | Pharmaceutical Manufacturing |
| Electronics & Semiconductor Water | Electronics Manufacturing, PCB Factories |
| Chemical Liquid Filtration | Chemical Processing Plants |
| Paint & Coating Filtration | Paint and Coating Manufacturers |
| Ink Filtration | Printing Industry |
| Cosmetics Production | Cosmetics & Personal Care |
| Brewing & Distillery | Beer, Wine, Spirits Production |
| Dairy Processing | Milk and Dairy Factories |
| Edible Oil Filtration | Palm Oil, Coconut Oil Processing |
| Sugar Processing | Sugar Mills |
| Bottled Drinking Water | Drinking Water Plants |
| Cooling Water Filtration | Industrial Cooling Systems |
| Boiler Feed Water | Steam Boiler Systems |
| Cooling Tower Water | HVAC & Industrial Facilities |
| Reverse Osmosis Pretreatment | RO Water Systems |
| Wastewater Reuse | Industrial Wastewater Treatment |
| Electroplating Solution Filtration | Metal Surface Treatment |
| Textile Process Water | Textile & Dyeing Factories |
| Aquaculture Water Filtration | Fish & Shrimp Farming |
| Laboratory Water Systems | Laboratories & Research Centers |
Export Packaging – Pleated Filter Cartridge
For Southeast Asia Market (Food & Beverage / Manufacturing / Water Treatment)
Standard Export Packaging
Each pleated filter cartridge is individually packaged to help keep the filter clean during transportation and storage. Multiple cartridges are packed in strong export cartons suitable for international shipping.
Packaging Details
| Item | Description |
|---|---|
| Individual Packaging | Sealed PE protective bag |
| Inner Protection | Protective plastic sleeve (Optional) |
| Outer Packaging | Heavy-duty export corrugated carton |
| Carton Type | Moisture-resistant carton for export logistics |
| Cushioning Material | Foam inserts or protective dividers (Optional) |
| Pallet Type | Fumigation-free plywood pallet or plastic pallet (Optional) |
| Pallet Wrapping | Stretch film with reinforced packing straps |
| Moisture Protection | Waterproof wrapping available for sea freight |
| Labeling | Product model, micron rating, quantity, batch number, carton mark |
| OEM Packaging | Private label and customized packaging available |
Packaging Features
Individual protective packaging helps reduce contamination before installation.
Durable export cartons provide additional protection during transportation.
Optional palletized packing supports efficient loading and unloading.
Moisture-resistant packaging is suitable for long-distance ocean shipping.
Clear carton labels improve warehouse identification and inventory management.
Flexible packaging options are available for OEM and private label projects.
Shipping Options
Sea Freight
Air Freight
Express Delivery
Full Container Load (FCL)
Less than Container Load (LCL)
Container Loading Reference
| Container Type | Loading Capacity* |
|---|---|
| 20GP | According to cartridge size and packaging configuration |
| 40GP | According to cartridge size and packaging configuration |
| 40HQ | According to cartridge size and packaging configuration |
*Actual loading quantity depends on the cartridge dimensions, packaging method, and customer requirements.
OEM & Custom Packaging Services
Custom carton printing
Private label packaging
Barcode labels
Product identification labels
Multilingual packaging labels
Customized carton dimensions
Mixed-model packing available
Export documents prepared according to customer requirements
This export packaging solution is designed for international distribution to Southeast Asian food & beverage, manufacturing, and water treatment industries, helping protect products during storage, handling, and transportation while supporting efficient logistics and warehouse operations.
FAQ – Pleated Filter Cartridge for Southeast Asia Market
(Food & Beverage / Manufacturing / Water Treatment)
1. What is a pleated filter cartridge used for?
A pleated filter cartridge is designed to remove suspended solids, fine particles, and contaminants from liquids. It is widely used in water treatment, food and beverage processing, manufacturing, and RO pretreatment systems.
2. Which filter media are available?
Common filter media include Polypropylene (PP), PES, PTFE, Nylon (PA), and Glass Fiber. The appropriate material depends on the liquid being filtered, operating conditions, and required filtration performance.
3. What micron ratings are available?
Pleated filter cartridges are available in a wide range of filtration ratings, including 0.1, 0.22, 0.45, 1, 3, 5, 10, 20, 30, 50, and 100 microns, making them suitable for both fine and coarse filtration applications.
4. Which industries commonly use pleated filter cartridges?
They are commonly used in:
Food and beverage production
Bottled water plants
Industrial water treatment
Electronics manufacturing
Chemical processing
Pharmaceutical support processes
General manufacturing facilities
5. Can pleated filter cartridges be used for RO pretreatment?
Yes. Pleated filter cartridges are commonly installed before reverse osmosis (RO) systems to reduce sediment and suspended particles, helping protect downstream membranes and improve overall system efficiency.
6. What cartridge sizes are available?
Standard lengths include 10 inch, 20 inch, 30 inch, and 40 inch. Different lengths can be selected based on system design and required flow capacity.
7. How often should a pleated filter cartridge be replaced?
Replacement frequency depends on water quality, contaminant levels, operating pressure, and system conditions. Regular monitoring of pressure drop and filtration performance helps determine the appropriate replacement interval.
8. Are different end cap configurations available?
Yes. Common connection options include DOE, 222 Flat, 222 Fin, 226 Flat, and 226 Fin, allowing compatibility with a wide range of industrial filter housings.
9. Can pleated filter cartridges be used in food and beverage applications?
Yes. Models manufactured with food-contact suitable materials are available for beverage production, bottled water processing, and food manufacturing where material compatibility is required.
10. How do I choose the right pleated filter cartridge?
When selecting a cartridge, consider the following factors:
Required micron rating
Filter media compatibility
Operating temperature
Flow rate
Cartridge length
End cap style
Liquid type and application
Selecting the appropriate specification helps achieve stable filtration performance and supports efficient system operation.
