Key Features
✔ Ultra-Chemical Resistance – Withstands acids, alkalis, solvents, and oxidizing agents
✔ Non-Stick Surface – PTFE’s low adhesion prevents fouling and simplifies cleaning
✔ High Purity Compliance – Zero contamination risk for pharmaceutical and food processes
✔ Lightweight & Flexible – Easy to handle and install in complex vessel geometries
✔ Customizable Properties – Variable density, thickness, and hybrid material options
Applications
Chemical Processing – Chlor-alkali cells, acid scrubbers, reactor venting
Pharmaceuticals – Fermentation off-gas, distillation, solvent recovery
Food & Beverage – Steam sterilization, flavor extraction, CIP systems
Semiconductor – Wet process exhaust, chemical vapor deposition (CVD)
Environmental – Stack gas scrubbing, wastewater treatment exhaust
Advantages
✅ Zero Metallic Contamination – Ideal for high-purity industries
✅ Exceptional Durability – Resists UV, aging, and chemical degradation
✅ Low Maintenance – Clean-in-place (CIP) compatible and steam sterilizable
✅ Regulatory Compliance – Meets FDA, USP Class VI, and EU 10/2011 standards
Specifications
Materials:
PP (Polypropylene): For temperatures up to 100°C
PTFE (Polytetrafluoroethylene): For temperatures up to 260°C
Mesh Density: 150–300 kg/m³ (customizable)
Efficiency: 99.5% for droplets ≥5 microns (PTFE); 99% for droplets ≥10 microns (PP)
Pressure Drop: 50–300 Pa (depending on face velocity and density)
Standard Thickness: 100mm, 150mm, 200mm
