Key Features
✔ Ultra-High Tensile Strength – Ranges from 100 kN/m to 1000 kN/m for heavy-duty reinforcement.
✔ Low Creep deformation – Maintains structural integrity under sustained loads.
✔ Excellent Flexibility – Adapts to uneven terrain and seismic activity without compromising performance.
✔ Chemical & UV Resistance – Polymer coating protects against soil chemicals and environmental degradation.
✔ Customizable Apertures – Rectangular or square mesh patterns for optimal soil interlock.
Applications
Reinforced Soil Walls – Vertical and near-vertical retaining structures.
Embankment Stabilization – Support over soft soils and steep slopes.
Landfill Capping & Base Layers – Enhances containment system integrity.
Bridge Abutments – Reduces differential settlement and lateral pressure.
Mining & Quarry Reinforcement – Stabilizes haul roads and waste dumps.
Advantages
✅ Long Service Life – Resists biological degradation and chemical corrosion.
✅ Cost-Effective – Reduces need for traditional materials like concrete and steel.
✅ Easy Installation – Lightweight rolls simplify handling and deployment.
✅ Sustainability – Low carbon footprint compared to conventional reinforcement methods.
Specifications
Material: High-tenacity polyester yarns with PVC or modified asphalt coating.
Tensile Strength: 100–1000 kN/m (machine direction).
Aperture Size: 20–50 mm (adjustable based on design requirements).
Elongation at Break: ≤12% (ensures minimal deformation under load).
Roll Dimensions: 2m–6m width × 50m–100m length.
Standards: ASTM D6637, ISO 10318, GRI-GG7.
