1. Precision Filtration: Removes 99% of contaminants, ensuring ultra-pure liquids for food, beverage, and pharmaceutical processes.
2. Durable Stainless Steel Construction: Resists corrosion and wear, maintaining consistent performance in demanding industrial environments.
3. Frequent Cartridge Replacement: Stop downtime and reduce maintenance costs with multi-cartridge high-flow housing.
4. Contamination Risk: Prevent cross-contamination with FDA-approved sanitary seals and polished surfaces.
5. 150 PSI Rated Pressure: Handles high-pressure filtration, 2x stronger than standard housings, for industrial-grade reliability.
6. Up to 40 Cartridges Capacity: Supports large-scale operations, filtering up to 300 m3/h, maximizing productivity.
7. Industrial Water Treatment: Perfect for chemical, pharmaceutical, and beverage plants, ensuring safe and clean output.
8. Sanitary Processing Environments: Mirror-polished SS316L housing keeps liquids hygienic, minimizing contamination risks.
9. High Flow vs Standard Housing: Achieves 2x throughput with compact design, saving space in tight industrial layouts.
10. 316L vs 304 Stainless Steel: Offers superior corrosion resistance for aggressive chemicals and long-term durability.
Food Grade Stainless Steel Filter Housing Specification：
| Material | SS304, SS316, 316L |
| Surface Finish | Mirror Polish, Electro-Polished, Sand Blasted |
| Cartridge Quantity | 1-160 Cartridges |
| Cartridge Diameter | 2.5", 2.75", 5" High Flow |
| Filtration Type | Liquid Filtration |
| Design Pressure | 150 Psi (10 Bar) Standard |
| Max Operating Pressure | 150-300 Psi (Customized Available) |
| Operating Temperature | 0°C to 120°C |
| Inlet/Outlet Connection | Flange, Tri-Clamp, NPT, Bsp Thread |
| Vent Connection | 1/4" NPT |
| Drain Connection | 1/2" NPT or Customized |
| O-Ring Material | Silicone, EPDM, PTFE |
| Closure Type | Swing Bolt, V-Clamp, Eye Bolt |
| Flow Rate | 1-300 M³/H |
Application | Water Treatment, Food & Beverage, Pharmaceutical |
Hygienic Filter Housing Standard Export Packaging:
1. Inner Protection
PE Protective Film
Bubble Wrap Protection
Dust-Proof Packaging
Moisture-Proof Protection
2. Outer Packaging
Reinforced Export Carton
Fumigation-Free Plywood Case
Export Wooden Crate for Large Models
Corner Protection Reinforcement
3. Shipping Protection Features
Anti-Corrosion Protection
Shock-Resistant Packaging
Moisture Barrier Wrapping
Secure Fixing During Transportation
Suitable for Sea Freight, Air Freight, and Railway Transportation
Packaging Information
Stainless Steel Filter Vessel FAQ：
Q: What materials are available for the filter housing?
A: Our stainless steel filter housings are manufactured from high-quality SS304, SS304L, SS316, and SS316L stainless steel, meeting the corrosion resistance and hygiene requirements of European industries.
Q: What filtration applications are suitable for this housing?
A: The housing is widely used for:
Water treatment
Beverage production
Food processing
Pharmaceutical manufacturing
Chemical filtration
Cosmetics production
Industrial liquid filtration
Q: What filter cartridges can be installed?
A: The housing is compatible with:
PP Melt Blown Cartridges
String Wound Cartridges
Pleated Filter Cartridges
Activated Carbon Cartridges
High Flow Filter Cartridges
Membrane Filter Cartridges
Q: What cartridge lengths are available?
A: Standard cartridge lengths include:
10", 20", 30", 40"
Custom lengths are available upon request.
Q: What is the maximum operating pressure?
A: Standard operating pressure ranges from 6 bar to 10 bar, depending on the housing model and configuration.
Q: Does the product comply with European standards?
A: Yes. Our filter housings can be manufactured according to relevant European requirements and can provide certificates such as:
ISO 9001
SGS Inspection Report
Material Certificate (EN 10204 3.1)
FDA Compliance for Food Contact Components (if required)
Q: Can customized inlet and outlet connections be provided?
A: Yes. Available connection types include:
BSP Thread
NPT Thread
Flange Connection
Tri-Clamp Connection
DIN Standard Connection
Q: What industries in Europe commonly use stainless steel filter housings?
A: Popular industries include:
Municipal Water Treatment
Food & Beverage
Dairy Processing
Brewing Industry
Pharmaceutical Plants
Chemical Processing
Electronics Manufacturing
Q: Do you offer OEM and private label services?
A: Yes. We support:
Custom Logo Engraving
Customized Nameplates
Special Surface Finishes
Custom Dimensions
OEM Packaging
Q: What is the service life of the housing?
A: Under proper operating conditions and routine maintenance, stainless steel filter housings can provide a service life of 10 years or more.
