Benefits
Low pressure drop, easy installation
Energy-saving
Light weight
100% integrity testing before package
Application
Widely used as terminal filtration of cleanroom in OT room and lCU room of hospitals laboratory, pharma industry, electronic equipment food industry, fiber optical equipment etc.
Product Information
Filter media：Glass fiber / PTFE/PP
Frame：MDF /Aluminum
Sealant：Two component polyurethane glue
Gasket：EPDM / EVA/ PU foamed
Separator：Hot-melt adhesive
Frame depth (mm)：461501691901961100/110/1201150
Protective net：Both sides
Max.working temperature：70℃
Technical Parameter
| Size (mm) (WxHxD) | Rated air flow (m³/h) | Face velocity (m/s) |
| 305x610x50 | 800 | 1.2 |
| 610x610x50 | 1600 | 1.2 |
| 610x610x70 | 1600 | 1.2 |
| 1170x570x70 | 2800 | 1.2 |
| 610x610x80 | 1600 | 1.2 |
| 610x915x80 | 2400 | 1.2 |
| Clean pressure drop (Pa) | |||
| H10 | H11 | H13 | H14 |
| 120 | 180 | 250 | 270 |
| 120 | 180 | 250 | 270 |
| 85 | 145 | 220 | 240 |
| 85 | 145 | 220 | 240 |
| 75 | 135 | 215 | 230 |
| 75 | 135 | 215 | 230 |
Final pressure drop (Pa)：2-2.5 times of clean pressure drop
