Key Features
✔ Advanced Filtration – Traps fine particles (PM2.5, allergens, and pollutants) for cleaner air.
✔ High Airflow Efficiency – Low resistance design maintains cooling/heating performance.
✔ Durable & Washable – Reusable mesh (optional: disposable filters available).
✔ Anti-Bacterial & Anti-Static – Optional treatments to inhibit mold and dust buildup.
✔ Universal Fit – Compatible with window ACs, split systems, and central HVAC units.
Available Types
Standard Fiberglass Filter – Cost-effective dust capture.
Pleated Electrostatic Filter – Enhanced particle retention.
HEPA Filter – Medical-grade filtration (99.97% efficiency).
Activated Carbon Filter – Odor & VOC removal.
Specifications
Material: 100% Nylon (Polyamide)
Mesh Type: Monofilament Plain Weave
Color Options: White/Gray/Black/Custom
Thickness: 0.3mm-1.2mm (±0.05mm)
Width: 0.5m-3m (Customizable)
Length: 10m-100m per roll
| Mesh Count | Thread Diameter | Open Area % |
| 20 mesh | 0.35mm | 52% |
| 40 mesh | 0.25mm | 48% |
| 60 mesh | 0.18mm | 42% |
| 80 mesh | 0.15mm | 38% |
| 100 mesh | 0.12mm | 35% |
Filtration Performance:
Filtration Efficiency: 85%-98% (varies by mesh count)
Particle Retention: 50μm-200μm
Air Permeability: 800-2500L/m²/s (@200Pa)
Dust Holding Capacity: ≥150g/m²
Physical Properties:
Tensile Strength: ≥50N/cm (warp & weft)
Elongation at Break: ≤15%
Temperature Resistance: -40°C to +120°C
Flame Retardancy: UL94 V-2 (Optional)
Packaging:
Standard: Roll form with PVC tube core
Protection: Plastic wrapped + carton box
