Specifications
| Size type | Ø×L （mm) | Flow(m³/h) | Filtration area (m²) | Volume (L) |
| #1 | φ180×430 | ~20 | 0.24 | ~8 |
| #2 | φ180×810 | ~40 | 0.48 | ~17 |
| #3 | φ105×230 | ~6 | 0.08 | ~1.3 |
| #4 | φ105×380 | ~12 | 0.16 | ~2.6 |
| #5 | φ150×560 | ~20 | 0.24 | ~8 |
Filtration accuracy: 0.05–200µm is optional, and the common accuracy is 0.5, 1, 5, 10, 25µm.
Filtration efficiency: relative efficiency is about 85%; single filtration efficiency of coating/film layer can reach more than 99%.
Gas filtration fineness: PTFE membrane surface filtration efficiency of 0.2–3µm pore size reaches 99.99%.
Advantages and Features
Extreme environment resistance: resistant to high temperatures of 260–300°C, chemically stable at pH 1–14.
Efficient ash removal: Smooth surface has low adhesion, suitable for pulse/backblowing ash cleaning.
Low pressure drop design: high air permeability combined with coating film structure, effectively reducing system energy consumption.
Long service life: high mechanical strength, and can be used for more than 12,000 hours.
Application scenarios
High temperature industrial flue gas: filter bag dust removal such as power plants, steel plants, incinerators, etc.
Chemical process: strong acid, strong alkali or corrosive particles capture.
Food/Pharmaceutical: High cleanliness requirements, no pollution in the materials, no shedding particles.
Environmentally friendly emissions: Comply with strict emission standards, high particle filtration efficiency of PM0.2–3µm.
